Bowers & Wilkins DB4S Subwoofer - (Each)
Overview
The Bowers & Wilkins DB4S is a single-driver subwoofer in the DB Series, built around a 10-inch Aerofoil cone driver, the same cone technology used in the 800 Series Diamond speakers, powered by a 1000-watt Class D Hypex amplifier in a sealed enclosure. It's a compact, classically styled match for the 700 Series.
Because it's a closed-box design rather than a ported one, the DB4S favours tight, controlled bass over the higher maximum output of a vented cabinet, reaching down to 8.5Hz. A digital preamplifier with Dynamic EQ keeps the tonal balance consistent across volume levels, and setup runs through a dedicated Bowers & Wilkins app with Bluetooth Low Energy control.
On the back panel, dual XLR and RCA inputs, twin 12V triggers, and an RS-232 port let it wire into either a stereo system or a custom control setup, and it's available in Gloss Black, Satin White, or Rosenut to match a 700 Series pair.
Simcoe Audio Video Insight
For home theatre and stereo systems across Central Ontario built around the 700 Series, the DB4S is sized and finished to sit alongside those speakers rather than stand out as an add-on box. Its RS-232 port gives our installers a straightforward way to bring it into a whole-home control system, and the sealed cabinet keeps the low end tight rather than boomy in smaller or more acoustically live rooms.
More Info
Why the DB4S Stands Out
1000W Class D Hypex Amplifier
A digital amplifier platform paired with a digital preamplifier for consistent, controlled output.
10-Inch Aerofoil Cone Driver
The same Aerofoil cone technology used in the 800 Series Diamond speakers, in a single-driver configuration.
Sealed (Closed-Box) Enclosure
A closed-box design that favours tight, controlled bass extension down to 8.5Hz.
Dynamic EQ Digital Preamplifier
Keeps output linear and controlled across the available frequency range, set up and adjusted through a companion app.
Balanced XLR & RCA Inputs
Dual XLR and dual RCA inputs allow connection to both professional and consumer-level systems.
RS-232 & Dual 12V Trigger Control
Built-in RS-232 and two 12V trigger inputs for integration into custom control and automation systems.
Matched 700 Series Finishes
Available in Gloss Black, Satin White, or Rosenut to pair visually with a 700 Series speaker system.
Buyer's Guide
Who It's For
- 700 Series owners: A subwoofer sized and finished to match a 700 Series speaker pair.
- Home theatre builds: Buyers who want a single, compact subwoofer rather than a dual-driver cabinet.
- Custom home theatre installers: RS-232 control makes it straightforward to bring into a whole-home automation system.
How It Compares
The DB4S and the Bowers & Wilkins DB3D take different approaches to compact bass. The DB3D uses two 8-inch drivers in a balanced, cabinet-cancelling configuration, while the DB4S uses a single, larger 10-inch driver in a classic sealed cabinet. Both share the same 1000W Class D Hypex amplifier platform; the DB3D's balanced layout suits rooms where cabinet vibration is a concern, while the DB4S is built to match the look of a 700 Series pair.
Bowers & Wilkins DB4S Subwoofer - (Each) Specifications
| General Information | |
|---|---|
| Model | DB4S |
| Brand | Bowers & Wilkins |
| Type | Active closed-box subwoofer system (Each) |
| Available Finishes | Gloss Black (with Black grilles), Rosenut (with Black grilles), Satin White (with Grey grilles) |
| Driver Specifications | |
| Bass Driver | 1x ø250mm (10 in) Aerofoil™ cone bass unit, closed-box configuration |
| Crossover Network & Control | Digital preamplifier with Dynamic EQ; app-based setup and control via Bluetooth Low Energy |
| Acoustic Performance | |
| Frequency Response (Centred on Level at 100Hz) | 10Hz - 350Hz (-3dB) |
| Frequency Range | 8.5Hz - 500Hz (-6dB) |
| Signal to Noise Ratio | 82dB |
| Input Impedance | RCA: 10kΩ / XLR: 20kΩ |
| Power, Construction & Connectivity | |
| Amplifier | 1000W Class D Hypex amplifier (Max power output) |
| Power Consumption | 195W (at 1/8th rated power) / <0.5W standby |
| Cabinet Build | Rigid, sealed (closed-box) enclosure |
| Inputs | 2x XLR, 2x RCA, 2x 3.5mm 12V trigger, RS-232 (9-pin D connector) |
| Dimensions & Weight | |
| Dimensions with Feet (h x w x d) | 14.8" x 14.1" x 14.5" (377 mm x 360 mm x 368 mm) |
| Weight | 57.3 lbs (26 kg) |
